As per the structural drawing.

a) Nature of Work : Concrete

R.C.C Footing : As per structural Requirement

R.C.C Column starter : 1:1:2

R.C.C Column : As per structural Requirement

Roof : As per structural Requirement.

Brand name of cement : penna OPC 53 Grade

Brand Of Steel : ARS for structural works: Fe550 steel for other works

b) Nature of work :  Brickwork.

Nature of material : First quality machine RED BRICK.

Size : 9”x4 ½” x3”

Ratio of cement/sand : 1:4 for 4.5” wall and 1:5 for 9”wall.

Wall thickness : As per Schematic Drawings.

Brand name of cement : penna OPC equivalent.

Reinforcements for every 4th course should be provide at in the case of 4.5″ brickwork by using metal straps.

Sill Slab : Continuous 3″ thick Rcc Sill Slab will be provided for all walls (4.5” and 9” to avoidcracks )

1. c) Nature of work : Plastering.

Nature of material used : Cement /Plastering M-sand.

Cement / Sand ratio : 1:3 for ceiling & 1:5 for internal wall.

Brand name of cement : Ramco PPC or equivalent

INNER PLASTERING

Ceiling : Sponge Finish.

Walls : Trowel run finish

OUTER PLASTERING

Ceiling & Sunshade : Sponge Finish

Walls : Sponge finish and Edges will befinished with cement paste.

d) FLOORING

Item of Works : Flooring.

Type of Flooring : Joint Free Vitrified Tile Flooring with 4”skirting – basic rate Rs.80/-Sft .

Nature of work : Bathroom Wall.

Place of application : Bathrooms – 7`0” Ht from Floor level

Type of material : Glazed. (Rs.55/-Sft.)

Type of work : Bathroom Flooring.

Nature of material : Ceramic (Antiskid) floor tile. (Rs.50/-Sft.)
Size : 12”x12”

a) Main Door

Teak wood frame (sections 5” x 3”) and Teak wood panel door of size 3’-6” x 7„-0”(app RS.20,000/-) of thickness 1½” with both side varnished with design beeding provided with lock & brass fittings – Handles and tower bolts, Door Eye and Aldrop. Normal design, Safety Grill with 12mm square rods will be provided.

Type of Wood : 1 st quality teak

Size of frame : 5” x 3”x 7‟0”.

Nature of finishing : both side varnish / mahogany.

Hinges : 6″ – Brass

Tower bolt : 8” Tower bolt top, 6″ at center ( Brass ).

Screws : Brass Screws.

Doorstopper : heavy duty (Brass).

Magnetic Catch /Bush :  Bush

b) Bedroom Doors:

Teak Wood of Rs.1950 per cft Frame (sections 4” x 2 1/2”) with Skin door / Marine ply flush Door 32 mm thickness painted with primer, putty and 2 coats of enamel paint – Asian brand with lock & Handles, and tower bolts.

Hinges : 6”size oxidised Hinges

Tower bolt : 8” Tower bolt top, 6″ at center.

Screws : Star screws.

Doorstopper : heavy duty – Stainless Steel

Magnetic Catch /Bush : Bush

c) Balcony/Service Doors

Teak Wood of Rs.1950 per cft Frame with (sections 4” x 2 ½”) resin coated Flush door 32 mm thick prestige brand with tower bolt and handle and other necessary fittings with door hooks on the back side.

Frame : 4” x 2 ½”

Type of shutter :

Flush Door (32 mm thickness).

Nature of finishing : Enamel Glossy Finishing.

Hinges : 5”size Stainless steel

Handle : 5″ Stainless Steel

Aldrops : 10 x 5/8. Stainless Steel

Tower bolt : 8” Tower bolt top, 6″ at center (Aluminium with SS finish)

Screws : Stainless steel screws.

Doorstopper : Heavy Duty – Stainless Steel.

Magnetic Catch /Bush : Bush

Hook : 5″ Stainless Steel

d) Bathroom Doors:

WPC Doors and Frames with tower bolt and handle and other necessary fittings.(SS hinges).

e) Windows

UPVC windows with openable shutters.

Type of Glass : 4mm pin headed glass

f) Ventilator

UPVC ventilators with Exhaust fan provision.

Safety Grills for Windows: 10mm M.S. Grills for all windows

Toilet & Bathroom sunken areas will be plastered by adding water proof chemicals.

a) Nature of work : Water line pipes.

Place of application :  Bathroom, water tank, Washbasin. Bore to Over Head Tank.

Type of material : PVC (Finolex) and CPVC (Ashirvad) For Concealed

Size : OHT-to-Terrace (Ring main ) -1.5”, Terrace to Bathroom -1”Bath inner distribution 3/4” (CPVC.)

b) Nature of work : Sewage pipe.

Place of Application : Waste line from bath & W.C, Washbasin.

Type of material : P.V.C.

Size of main sewage line : 5” Dia 6 Kg/cm2 PVC Pipe (Prince).

Size of other lines : 1.5” to 4” dia 6Kg/cm2  (Prince).

Open 2½” dia 4” dia waste and soil lines will be of minimum 4 kg / cm2 of finolex brand Proper pipes and chambers along Gully with the required Soak pits will be done for Rain Water Harvesting and disposal of other wastes.

c) Nature of work : CP fittings.

CP fittings Brand : Parryware UNO or equivalent

CP FITTINGS LIST

Shower Arm+ : 1 No each for attached and commonShower Rose (min 9″) bathrooms.

2 in 1 Wall Mixer with : 1 No each for attached and common Bend bathrooms.

1/2 ” Long Body Tap : For IWC and Kitchen Sink.

1/2″ Two in one Bib cock with Health Faucet : For EWC

1/2 ” Short Body Tap : Kitchen Service Area

1/2″ Pillar Cock : one number for each wash basin

1/2 ” Angle way Cock : 1 No each for Washbasin,

Flush Tank and geyser

1/2 ” CP Flanges: Wherever applicable and necessary

1/2″ H/W Connection: For Angle way cocks and geysers

1 1/4″ CP Half/ full thread: For wash Basins

Sink Cup: For Kitchen Sinks

1 1/4″ PVC Spring Waste: For wash Basins and Kitchen Sink

PVC Bottle Trap arrangement: For Wash Basins and Kitchen Sink

Holes Gratings : Wherever applicable and necessary

Plain Gratings : Wherever applicable and necessary

Any other CP fittings which are not mentioned are to be provided as a where necessary.

d) Sanitary Fittings:

Western Closet with flush Tank (Parry ware Brand slimline tank ) 2 way Bib Cock, Angle way cock and health faucet (Parryware company or higher).

Wash Basin (Parry ware) White 1 No each of Size 18” x 12”(Indus Standard or Tapti ) with approved C.P fittings (1/2″ Pillar Cock , 1/2 ” Angle way Cock, PVC Spring Waste, 1 1/4″ Half Thread etc,) will be provided for Hall/Dining, Common and Attached Bathrooms

Concealed Copper Wiring with Three phase electrical supply with manual phase changeover and DB of 63 / 90 Amps with ELCB along with provision for Inverter with the necessary and adequate circuit breakers for each flat.

ELECTRICAL

Nature of work: Electrical Works.

Type of conduit: Concealed.

Electrical Pipe: Roof – 2mm, Wall – 1.5mm.

Size of pipe: 3/4″ and 1”.

Switches: Anchor Roma white switches with anchor metal box

MCB’s : legrand

Wire & cables.

Wires : Orbit

Concealed multi strand copper wiring with color differentiation for Phase,

Neutral,Earth and Inverter wires.

6 sq.mm : Distribution board to paneling board

4 Sq.mm : For AC,Geyser and Motors

2.5 Sq.mm : From The Distribution Board to the switchboard and Wiring for all other equipment Fridge, washing machine ,etc and 5 Amps

1.5 Sq.mm: Earth Wire (Green Color only for earth)

1 Sq.mm: For lights and fans.

Inverter Wiring: Grey colour 2.5 Sq.mm from Inverter to DB and 1.5 Sq.mm from DB to Switch Board

Electrical Points in Each Area

HALL

• 3 Phase manual phase Changeover
• Three Light Points.
• One Calling Bell Point.
• One / Two Fan Points with regulators and One chandelier point
• One T.V. Point – built in Aerial
• Four 5 Amps Point. (2 No along with TV and 1 No each in switchboxes)
• 1 No Telephone Point along with 5 Amps point
• 1 A/C point.
• 1 two way light point for main entrance door

DINING AREA

• 2 Nos. – Light Points.
• 2 Nos. – 5 Amps.
• 1 No. – 15 Amps. For Fridge.
• 1 No. – Fan Point.

EACH BEDROOM

• One / Two Fan Points with regulators according to the size of the bedroom.
• Two Light Points.
• One Night Lamp.
• One No. 25 Amp. A.C. Point with Metal box.
• 5 Amps. Sockets – 2 Nos. separately.
• Switch box with 5 Amps. Socket (Board)
• Two-way switch for one fan and light.
• One TV point along with 2nos- 5 Amps points in the Master Bedroom.
• One 5 Amps point for Computer in other Bedrooms
• 1 No Telephone Point along with 5Amps point in the Master Bedroom with internet point

BATHROOM

• Two Light Points in each toilet.(one in wall and one above wash basin mirror)
• One Geyser Point – 15 Amps.
• One 5 Amps point near the wash basin
• One exhaust fan point.

KITCHEN

• One Fan Point .
• Two Light Points.
• Two sets of (15 Amps and 5 amps Point)
• One 5 Amps Points in the switchboard
• One Exhaust Fan Point.

KITCHEN SERVICE

• One light point
• One 15 amps point for Washing Machine

HALL / BEDROOM BALCONY

• One light point for Bedroom Balcony and Hall Balcony.

STAIRCASE FLIGHT

• One light point in the mid landing wall
• Two No – Two way light points for the staircase flight

CORRIDOR

• Adequate Light Points as required.

CAR PARKING AREA

• 2nos 15 amps points for sump and bore Motor with 4sqmm wiring

Adequate Light Points according to the client’s requirement

Nature of work : Painting and Color washing.

Inner Ceilings : Two coats of Premium emulsion (white) over one coat of white cement.

Outer Ceilings : Two coats of Apex Emulsion (white) over one coat of white cement

Inner Walls : Two coats of Premium Emulsion over one coat of Wall Primer and Two coat of Putty.

External Walls: Two coats of Apex over one coat of wall primerMetal Grills (Window) 1 Coat Metal Primer +2 Coats Enamel Paint (Compound Gate, Balcony) (Black and White)

Nature of work. : Grill Work.

Place of Application : Windows.

Type of Material : M.S Square 10mm Rods.

Nature of Painting : Satin Enamel 2 coats over 1 coat of zinc primer.

• Bedroom Storage

  Open Wardrobe / Cupboard Size min 7 x 4 with 1” cuddappah slab partitions

  Loft – 1 No (Each) 2‟ 0” Depth.

  Kitchen Storage

  (Open Shelf – Cuddappah Stone) 4‟-0” x 7‟-0” – 1No Depth of 15″Loft -1‟ 9” Depth

  Toilet Storage

  One/Two semicircular slab of either granite/cuddappah at one end.

  Inverter

  One loft for inverter as per architects drawing

• Cooking Platform – Kitchen will be provided with a 2′-0″ wide platform top of 20mm G20 polished Black Granite , edge polishing and chamfered beeding with provision for gas tube hole.
• Single Bowl stainless steel sink (Diamond brand) with 2 taps one for well water, one for corporation water. (1/2″ long body tap) and 1 1/4″ CP Half thread, sink cup and angle cock for Aquaguard.
• Above cooking platform 4‟-0” height glazed tiles.
• One Exhaust Fan Point with 9″ round cut in the masonry wall with net in the outside.

• Toilet & Bathroom sunken areas should be concreted and plastered by adding water proof chemicals.
• One Ventilator for each bathroom size according to the Client.
• Exhaust fan provision will give along with the ventilator or a separate 9″opening in the outer wall should be given with outside net.

•  Vitrified 1` x 1` white weathering tiles over 2” of screed concrete with proper slope. waterproofing will be done in the terrace.

•  Steps and landings laid with granite stones or equivalent of Rs.70 perSq.ft with 2 grooves finished with edge polishing and edge champhering only. SS Grills handrails with 2″dia of 304 grade Jindal Steel.

• Pest control measures to prevent attack by white ants etc. at various stages such as Footing, Plinth beam basement etc., will be done.

• Water proofing for all sunken areas and shall add water proofing materials with cement whenever necessary and finish the Toilet floors, terrace areas to avoid dampness or leakages in future will be done
